https://image.makewebcdn.com/makeweb/0/B3VBlXlU2/Document/KTE2_TATUNG_TEFC_IE2.pdf?v=202405291424KTE2/KTE3 Series

Information

• Application : General purpose including cutting machines, pumps, fans, conveyors, mixer machines tools of farm duty
  and food process and mining Equipment.
• Use : The altitude not exceeding 1000m above sea level. The ambient temperature subject to seasonal variations
  but not exceeding + 40 °C and not less than -20°C.

• Starting Method : The following general 4KW motor for the "Y" connection, ≥ 4KW motor as "△"connection.

Outstanding Features

• Save energy & electricity cost
  The series meets or exceeds the IEC IE2 efficiency grade greatly contributes to energy and electricity cost saving.

• Extra low noise
  High efficiency and low loss fans improve cooling condition and smooth operation to achieve low noise level better than
  IEC standard.

• Low temperature rise and long lifetime
  With design of Class F insulation and class B temperature rise which extends the service life of the motor.

• Superior performance
  High starting torque and low starting current exceeds IEC standard and suitable for various applications.


• Guaranteed interchangeability
  The installation dimensions and output characteristics have complete interchangeability with existing IEC-base motors.

Additional Product Details File

Item	Download
Catalog-KTE3 Series-50Hz-IE3
KTE2-TATUNG TEFC IE2
