The performance curves are valid for pumping air at 15ºC at the inlet flanges with an air pressure of 1.013 mbar and a tolerance of ±10%. The total pressure differences are valid up to an intake and ambient temperature of 25ºC.
Additional Product Information File
| Item | Download |
| ARC 429 |  |
